Name: REVOTECH 8MP POE IP Camera: Best Affordable Security Solution
SKU: UPVEAF2D5QPW
Availability: InStock

REVOTECH 8MP 5MP POE Mini Type IP Camera Lens Indoor Metal Security ONVIF P2P CCTV System Video Surveillance Cam

– High Resolution 8.0/5.0 Megapixel 1/3'' CMOS Sensor

– 5MP 2880*1616Presolution / 8MP 3840*2160Presolution

– Support H.265 encode, compare with H.264, transit same quality image only need half of the bandwidth; Record same quality image only need half of the storage;

– Also support H.264 encode, so it can be compatible with both H.264 and H.265 device.

– Support iPhone, Android smart phone

– P2P Cloud Function

– Support Motion Detection, Email Alarm function

– Support web interface of IE6.0 and above browser.

– Net Weight: 0.23KG

– Metal Material Shell

– Simple Operation and Easy to Use

NOTE:

1. IP camera will create more heat and the case of this camera is small, so after you operate the camera for a while, you will feel the camera is hot. And do not worry, it is normal and safe, hope you can understand.

2. This camera default 8/5MP & H.265, if your NVR do not support 8/5MP or H.265, you can change our camera into 1080P (2MP) and H.264.

3."POE 48V" Option mean the camera support POE, can power from POE, need to connect with a802.3AF Standard 48V POE Switch (It have auxiliary power supply connector, can be used like a Non-POE IP camera).

4."DC 12V" Option mean the camera is regular version, do not support POE and it can only with with a 12V regular power.

5.This device do not support Cloud Storage, please do not purchase the Cloud Storage from the “Wanan Pro” app.

Camera

8MP:

Model: I706-2-HS82

Resolution:3840 x 2160P 5.0 Mega Pixels camera

Sensor: HI3516CV610+GC8613

Frame rate: 20fps

Min illumination: 0.01Lux @(F1.2,AGC ON)

Shutter: 1/25 seconds -1/100,000 seconds

Lens: 3.7mm

Lens interface type: M12

Compression Format: H.264 / H.265

Compression rate output: 128 Kbps~8Mbps

Storage: NVR or Computer. This device do not support Cloud Storage, please do not purchase the Cloud Storage from the “Wanan Pro” app.

IP address: Dynamic (Default) / Static

Smart alarm: Motion detection, Email alarm

Support protocol: HTTP, TCP/IP, ICMP, RTSP, RTP, UDP, RTCP, SMTP, DHCP, DNS, PPPoE, NTP

Input protocol: The standard ONVIF

Onvif Port: 80

General function: A key recovery, dual stream, password protection, video hiding

Ethernet: 10M / 100M mbps Ethernet (RJ-45)

5MP:

Model: I706-2-HSWA

Resolution:2880 x 1616P 5.0 Mega Pixels camera

Sensor: HI3516CV610+GC5053

Frame rate: 25fps

Min illumination: 0.01Lux @(F1.2,AGC ON)

Shutter: 1/25 seconds -1/100,000 seconds

Lens: 3.7mm

Lens interface type: M12

Compression Format: H.264 / H.265

Compression rate output: 128 Kbps~8Mbps

Storage: NVR or Computer. This device do not support Cloud Storage, please do not purchase the Cloud Storage from the “Wanan Pro” app.

IP address: Dynamic (Default) / Static

Smart alarm: Motion detection, Email alarm

Support protocol: HTTP, TCP/IP, ICMP, RTSP, RTP, UDP, RTCP, SMTP, DHCP, DNS, PPPoE, NTP

Input protocol: The standard ONVIF

Onvif Port: 80

General function: A key recovery, dual stream, password protection, video hiding

Ethernet: 10M / 100M mbps Ethernet (RJ-45)

General

Operating Temperature: -25°C~60°C

Operating Humidity: 10%~90%

Power Supply:

POE 48V option support POE 48V(802.3af) & DC12V/2A

DC 12V option support DC12V/2A

Housing Material: Metal

Dimension:5.7 x 4.4 x 3.9cm

Weight: 0.25kg

Package Content

1 x Camera

1 x User Manual

1 x Screws Set

Power supply Note:

1.POE 48V version can power from POE, need to connect with a802.3AF Standard 48V POE Switch. if you need one, please click the picture to buy.

2.Both POE 48V version and DC 12V version have not include power adapter, if you need one, please click the picture to buy.

8MP Pictures:

5MP Pictures:

Browser View:

Software View

App View

Important Notice: This device do not support Cloud Storage, please do not purchase the Cloud Storage from the

“Wanan Pro” app.

NOTE:System 1 also can save the video by CMS software, but it need to set and open the computer all the time. It is not convenient, so we suggest your to use system 2 to save the video. It is stable and reliable.

1. We ONLY ship toConfirmed Order Address. Please make sure your address on the order is up to date.
2. Item will be shipped within 1-3 business days after payment confirmed.
3. Buyer is responded for all VAT, duties, taxes and any other extra fee under any circumstances.
4. If you do not receive your package within 45 days after we shipped it, please contact us. We will check the shipment and reply you as soon as possible.

1. Item will be checked and packaged in good condition before shipping out.
2. If you have any problems of our product, please contact with us first and we will help you to solve the problems.
3. Item comes with 12months warranty against any manufacturer defects: Free replacement service (Product or Defective part) in 30 days; Free repair service in 12 months.
4. Unauthorized returns will be ignored. The return policy does not cover accidental damage due to misuse, abuse or improper care.

1. Q: How do I pay for my purchase?

A: We accept payment on Aliexpress or Paypal, if you need to pay by Paypal, please contact with us.

2. Q: Is there any Tracking Number for my item?
A: Yes, you can track it on the official website of the express methods or track it on 17track website.
http://www.17track.net/en

3. Q: I am a retailer, I would like to buy many piece of your item, what's the wholesale price?
A: Although our price is very cheap now, we do welcome the retailer and we can offer a better price for long term cooperation. So just be free to contact with us.

Feedback is important to us, please kindly leave a positive feedback if you are satisfied with our product and service, your support is our biggest motivation.
Please contact us first before giving a negative feedback, so that we can solve your problem and give you a satisfying resolution.

Weight	0.270 lbs
Dimensions	15 × 10 × 10 in
Brand Name	REVOTECH
Zoom type	none
Megapixels	8MP
Whether or Not 50Vac or 75Vdc or Higher Power Supply	No
Zoom	NONE
Origin	Mainland China
High Definition	8.0 Megapixels
High-concerned chemical	none
Lens Quantity	Single Lens
Supported Operating Systems	Windows 10, Windows Vista, Windows 8, Windows 7, Windows 98, Windows XP
Lens (mm)	3.7mm
Power Supply	With Poe
Style	Mini Camera
Connectivity	IP/Network Wired
Installation	Normal
Minimum Illumination(Lux)	NA
Scene	Indoor
Internal Storage	None
Video Compression Format	H.264, H.265
Certification	CE
Dimensions (L x W x D)(mm)	5.7 x 4.4 x 3.9cm
Shell Material	Metal
Color	black
Alarm Action	Email Photo
is_customized	Yes
Model Number	I706-2-HS
Supported Mobile Systems	iOS, Android
Smart home platform	NONE
AI Functions	Motion Detection
TF Card	None
Power Supply(V)	POE48V / DC12V
Audio Output	None
Sensor	CMOS
Operating Temperature	-10°-60°
Type	CCTV Camera
Model	IP Camera
LENS	3.7mm
TV Format	PAL/NTSC
White Balance	Auto
Resolution	5MP / 5MP
Colour	Black
Status	Brand New
Place of Origin	Guangdong, China (Mainland)
